Beschreibung
Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.
Spezifikationen
Anschlussgewinde
M 170x3
Außendurchmesser
244 mm
Breite
41 mm
Gewicht
8,40 kg
Gewinde
ISO 965/111-1980 tolerance class 6H
Höchstdruck
800 bar
Kolbenaußendurchmesser
235 mm
Kolbenbreite
7 mm
Kolbenfläche
9400 mm²
Kolbeninnendurchmesser
170.5 mm
Maximaldruck
80 Mpa
Maximale Kolbenschiefstellung
6 mm
