Riegler

3/2-Wegeventil

G 1/4, NC, 110 V AC monostabil, elektopneumatisch
Item-no.: 1734027Supplier number: 517.32.14.NC.110Acustoms tariff number: 84818079EAN: 4047322773959
Quantity: ​​ 1 PiecePackable​
Item available in 462 variants:
Short-term Sourcing
Description
3/2-way valve, electropneumatic, monostable, G 1/4, NC, 110 V AC, 50/60 Hz, p = 2.5 … 10 bar, aluminium. Traditional way valves of series 70 in electropneumatic version. These valves have a wide range of applications as bushing valves, direct mounting on the cylinder with special adapters or as series valves with multi-base plates and individual interlinking plates (supply strips).
Attributes
Actuation
monostable
Ambient temperature max.
50 °C
Ambient temperature min.
-10 °C
Connection
G 1/4
DN
7,5
Durchflusswertmessung 1
Durchfluss bei 6 bar und ∆p 0,5 bar
Durchflusswertmessung 2
Durchfluss bei 6 bar und Δp 1 bar
Flow rate 1
750 Nl/min
Flow rate 2
1100 Nl/min
Frequenz
50/60 Hz
Function
3/2 NC
Lieferumfang
mit Stecker und Spule
Manual override
resting
Max. operating pressure
10 bar
Medium
Filtered compressed air with or without oiling. If oiled, then continuously.
Medium temperature max.
60 °C
Medium temperature min.
-10 °C
Operating pressure min.
2,5 bar
Sealing material
NBR
Steuerluftanschluss
-
Steuerluftzufuhr
intern
Version
Electropneumatic
Downloads
Bedienungsanleitungbyhx_p_b-234.pdf
327.06 kB
Technische Dokumentation-dbyhx_145880.pdf
2.67 MB
