Rotary hammer with SDS-plus GBH 4-32 DFR
with a handyman's case Bosch 0.611.332.100Item-no.: 1049339Supplier number: 0611332100customs tariff number: 84672191EAN: 3165140412995
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Rotary Hammer with SDS plus GBH 4-32 DFR, The powerful GBH 4-32 DFR Professional with SDS plus delivers 4.2 J of impact energy with an 900 W motor for a very fast chisel removal rate. The rotary hammer is designed for durability, featuring a very robust metal gearbox housing. Its Vibration Control enables effortless and continuous work in time intensive applications. This rotary hammer is intended for drilling and chiselling in concrete, masonry, wood, and metal. It is compatible with various dust attachments. The GBH 4-32 DFR Professional also features a keyless and quick-change chuck, Reverse Mode, Rotation Control Clutch, Variable Speed, and Vario-Lock. Auxiliary handle (2 602 025 176), Depth stop 310 mm (1 613 001 003), SDS plus quick-change chuck (2 608 572 213), Machine cloth, Grease tube (spare part number 1 615 430 010), Carrying case
Attributes
Drill-Ø concrete with hammer drill
6 – 32 mm
Impact energy (according to EPTA 05/2016)
4.2 J
Impact rate at rated speed
0 - 3600 bpm
Impact rate at rated speed, from
0 bpm
Impact rate at rated speed, up to
3.600 bpm
Max. drill-Ø masonry, core bits
90 mm
Max. drill-Ø wood
32 mm
Max. drilling diameter in metal
13 mm
Nominal input power
900 W
Opt. application range concrete, hammer drill
14 – 25 mm
Packaging dimensions (width x length x height)
420 x 130 x 480 mm
Rated speed
0 – 800 min-1
Rated speed, from
0 min-1
Rated speed, up to
800 min-1
Rec. appl. range concrete, hammer drill bits, from
14 mm
Rec. appl. range concrete, hammer drill bits, to
25 mm
Schlagenergie
4,2 J
Tool dimensions (length)
493 mm
Tool holder
SDS plus
Voltage, electrical
230 V
Weight
4.7 kg
Werkzeugabmessungen (Breite)
377 mm
Werkzeugabmessungen (Höhe)
133 mm
