Description
Drill GBM 13-2 RE, The GBM 13-2 RE Professional is a corded 2-geared rotary drill designed for precision drilling. Its powerful 750 W motor and high torque deliver fast work progress, enabling the drilling of holes in steel of up to 13 mm in diameter. It features a compact and ergonomic design providing good tool handling for precise work. This rotary drill also features a 2-speed gearbox and a speed preselection setting wheel for accurate performance in versatile applications. This tool is intended for drilling in metal and wood. The GBM 13-2 RE Professional includes the option of selecting 1 out of 3 different chucks, and features right-left rotation, rotation control clutch, and speed selection, as well as variable speed. Keyless high-precision chuck, 1.5 - 13 mm (2 608 572 273), Auxiliary handle (2 602 025 190), Depth stop 210 mm (1 613 001 010), Cardboard box
Attributes
Drill chuck, design
Precision drill chuck
Drill spindle connnection thread
1/2"-20 UNF
Drill-Ø alu
20 / 12 mm
Drill-Ø alu, from
20 mm
Drill-Ø alu, to
12 mm
Drill-Ø steel
13 / 8 mm
Drill-Ø wood
32 / 20 mm
Idle speed, 1st gear
0 - 1000 min-1
Idle speed, 1st gear, from
0 U/min
Idle speed, 1st gear, to
1000 U/min
Idle speed, 2nd gear
3200 min-1
Idle speed, 2nd gear, from
3200 min-1
Measurement uncertainty k (drilling in metal)
7.5 m/s²
Measurement uncertainty k (screwing)
2.5 m/s²
Measurement uncertainty k [thread cutting]
2.5 m/s²
Nominal input power
750 W
Nominal torque
6.8 / 2.5 Nm
Nominal torque, 1st gear
6.8 Nm
Nominal torque, 2nd gear
2.5 Nm
Output power
353 W
Packaging dimensions (width x length x height)
276 x 358 x 83 mm
Rated speed
500 / 1750 min-1
Rated speed, 1st gear
500 min-1
Rated speed, 2nd gear
1750 min-1
Spindle neck diameter
43.0 mm
Tool holder
1/2"-20 UNF
Torque, max.
39.5 / 12.5 Nm
Torque, max. 1st gear
39.5 Nm
Torque, max. 2nd gear
12.5 Nm
Vibration emission value ah [Drilling in metal]
1.6 m/s²
Vibration emission value ah [Screws]
1.5 m/s²
Vibration emission value ah [Thread cutting]
1.5 m/s²
Voltage, electrical
230 V
Voltage, electrical, up to
230 V
Weight
2.4 kg
