Description
The drive is equipped with a collet tool mounting for mounted tools. The exhaust air flow is at the front. The extended version of the powerful drive for heavy-duty use has a high torque. Due to the lever throttle, the drive has a dead man's switch. The air grinder has to be used with oil. 3 m air supply hose with 1/4" male threaded connection and threaded quick coupling (STGI), 6 mm collet, 2 keys.
Attributes
Air consumption, at load
0.34 m³/min
Air consumption, idling
0.85 m³/min
Collet group
7
Exhaust air outlet
front
Height
46 mm
Incl. Ø collet [mm]
6 mm
Inner-ø supply air hose
8.5 mm
Length metric
350 mm
Net weight
1.6 kg
Number of oil droplets (min)
5 Drops
Operating pressure
6.3 bar
Power
600 Watt
Rotational speed
5000 RPM
Valve design
Lever
Version
with extension
Width metric
46 mm
