Compressed air motor
PMA 10/200 HV PferdItem-no.: 1516880Supplier number: 80703135EAN: 4007220384374
Quantity:
1 PiecePackable
Price and stock visible after login
Description
The compressed-air motor has a DIN 10 connection. The exhaust air flow of the air grinder is at the back. The drive may only be used with oil. Suitable extensions: STV 9, STV 13, STV 20, STV 27, STV 33. 1 m exhaust hose and 2.5 m air supply hose with 1/2" male threaded connection, 2 keys. Due to the lever valve, the drive has a dead man's switch.
Attributes
Air consumption, at load
1.1 m³/min
Air consumption, idling
1.38 m³/min
Connection coupling (DIN)
10
Exhaust air outlet
back
Height
46 mm
Inner-ø supply air hose
13 mm
Length metric
283 mm
Neu im Jahr
2022
Number of oil droplets (min)
7 Drops
Power
1000 Watt
Rotational speed
20000 RPM
Valve design
Lever
Width metric
46 mm
