Socket ratchet
1/2" mount, 14x18 mm square Gedore 7418-02Item-no.: 1032700Supplier number: 7418-02customs tariff number: 82079099EAN: 4002805748022
Quantity:
1 Piece
=
1 PackagingPackable
Price and stock visible after login
Description
For solving difficult assembly problems, easily replaceable, Forged, Chrome-vanadium steel, Matt chrome, With locking pin, Fine-toothed, Return angle 7°, Max. continuous load of ratchet according to DIN EN ISO 6789 and/or maximum load of cavity
Attributes
Antriebsvierkant (metrisch)
12,5 mm
Antriebsvierkant (zöllig)
1/2 "
Continuous load capacity
1/2" = 340 Nm
Drive socket rectangular
14 x 18 mm
Drive square
1/2 ″
Drive square mm
12,5 mm
Head height 1
28,8 mm
Head height 2
28,8 mm
Head width 1
47 mm
Holder mm
14 x 18 mm
Material
Chrome vanadium steel
Net weight
0,363 kg
Number of teeth
50
Return swivel angle
7,2 °
Stichmass (metrisch)
25 mm
Total width
47 mm
