Festkupplung
Storz 25-D KA 31 mm, IG 1/2", 16 bar AluminiumItem-no.: 1732906Supplier number: 2404.3112EAN: 4047322254557
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Storz adapter, Aluminium, Storz size 25-D, Tappet distance 31 mm, G 1/2 IT, Operating pressure max. 16 bar, Temp. -40 °C to 110 °C. High-quality series in forged aluminium. For quick and simple hose connections. User friendly, the coupling elements are joined without damaging the seal. Applications: Water lines, industrial plant engineering, firefighting.
Attributes
Betriebsdruck max.
16 bar
Betriebstemperatur max.
110 °C
Betriebstemperatur min.
-40 °C
Dichtmaterial
NBR
Innengewinde
G 1/2 IG
Knaggenabstand
31 mm
Material
Aluminium
Storz-Größe
25-D
