Straight grinder
GGS 8 CE Bosch 0.601.222.100Item-no.: 1049392Supplier number: 0601222100EAN: 3165140584852
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Straight Grinder GGS 8 CE, The GGS 8 CE Professional corded straight grinder offers uniquely powerful surface grinding in the straight grinder category. Its 750 W motor with soft start facilitates fast work progress. High torque and a handy design make the grinder ideal for use on surfaces with flap wheels, brushes, and other accessories. User protection is increased due to its KickBack Control feature. This tool is intended for grinding metal. The GGS 8 CE Professional also includes features such as constant speed, direct motor cooling, overload protection, and speed selection. Spanner 13 mm (spare part number 3 607 950 025), Spanner 19 mm (spare part number 3 607 950 024), Collet with locking nut 6 mm (2 608 570 137)
Attributes
Idle speed
2.500 – 8.000 min-1
Idle speed, from
2500 min-1
Idle speed, up to
8000 min-1
Max. collet Ø
8 mm
Max. grinding element Ø
50 mm
Max. polishing tool Ø
80 mm
Measurement uncertainty k (surface grinding up to Ø 25)
1,5 m/s²
Measurement uncertainty k (surface grinding up to Ø 50)
2,5 m/s²
Nominal input power
750 W
Output power
420 W
Packaging dimensions (width x length x height)
155 x 500 x 110 mm
Spindle neck diameter
43 mm
Spindle neck Ø
43 mm
Switch
Locking switch
Tool dimensions (length)
77 mm
Vibration emission value ah [surface grinding up to Ø 25]
2,5 m/s²
Vibration emission value ah [surface grinding up to Ø 50]
2,5 m/s²
Voltage, electrical
230 V
Weight
1,7 kg
Wrench surface clamping nut
19 mm
Wrench surface grinding spindle
13 mm
