Ganter

Grub screw with ball stud

GN 913.2-M5-8-A Steel 5.8, hardened tang
ST - Steel
Item-no.: 1214889Supplier number: 913.2-M5-8-AEAN: 4045525391734
PU (Packaging): 50 PieceQuantity: ​​ 1 PiecePackable​
Item available in 36 variants:
Short-term Sourcing
Description
Grub screws GN 913.2 with hardened spherical pivot (type A) are used in such cases where point contact is required. They are a lower cost alternative to ball point screws GN 605. Grub screws with hardened pointed pivot (type B) offer an alternative form of finish.
Attributes
Form
A - with ball stud
L2
1
Material
ST - Steel
R
2.5
RoHS
Ja
SW
2,5
Screw thread d1
M 5
Thread length l1
8
Weight
0.001 kg
d2
3
l3
0.5
