Riegler

Glycerine manometer class 1.6

AG 1/4", D63 mm, 0-16 bar, scale 0.5 CrNi steel, bottom connection
Item-no.: 1246088Supplier number: 748-63customs tariff number: 90262040EAN: 4047322354028

Quantity: ​​ 1 PiecePackable

Item available in 68 variants:
Short-term Sourcing

Description
Glycerine pressure gauge CrNi steel design, Connection radial bottom, G 1/4, Goods class 1.6, Measurement range 0 - 16 bar, Ø 63. Glycerine-filled bourdon-tube pressure gauge, CrNi steel type. For use in the chemical/petrochemical process industry, power stations, machinery and industrial plant engineering. For measurements in areas with high, dynamic pressure loads and vibration levels. Suitable for gaseous and liquid, corrosive, not highly viscous and non-crystallizing media, also in corrosive atmosphere.
Attributes
Ambient temperature max.
60 °C
Ambient temperature min.
-20 °C
Connection
G 1/4
Connection position
Radial bottom
Diameter
63 mm
Housing
Stainless steel 1.4301
Lower / upper measuring range limit
Overpressure
Material
CrNi steel
Material process connection
CrNi steel
Measuring range max. bar
16 bar
Measuring range min. bar
0 bar
Medium temperature max.
100 °C
Medium temperature min.
-20 °C
Quality class
1.6
Riegler article number
102321
Scale graduation in the bar range
0,5 bar
Screw thread
G 1/4 AG
Type
233.50
Viewing window
Polycarbonate
