Carbide burr KUD 0605/6 Z3 PLUS
Ø 6 mm x L 5 mm Shank Ø 6 mm Spherical shape, horseItem-no.: 1017826Supplier number: 21112526customs tariff number: 82077010EAN: 4007220046821
Quantity:
1 PiecePackable
Item available in 15 variants:
Price and stock visible after login
Description
Cut 3 PLUS is cross cut and especially well-suited to machining of cast iron, steel, stainless steel (INOX), nickel-based alloys and titanium alloys. It is characterized by its high stock removal rate. Tungsten carbide burrs for general applications are suitable for fine and coarse stock removal on the key materials used in industrial manufacturing. They provide a good stock removal rate and are not specific to a particular material. Ball-shaped burr according to DIN 8032 with cut conforming to DIN 8033.
Attributes
Cutting material
Carbide
Form
KUD
Head length
5 mm
Length, toothed
5 mm
Length, total
45 mm
RPM from, grey cast iron, white cast iron
24000 RPM
RPM from, hardened and tempered steels over 1,200 N/mm²
13000 RPM
RPM from, high-temperature resistant materials
13000 RPM
RPM from, stainless and acid-resistant steels
13000 RPM
RPM from, steels up to 1,200 N/mm²
24000 RPM
RPM up to, grey cast iron, white cast iron
32000 RPM
RPM up to, hardened and tempered steels over 1,200 N/mm²
19000 RPM
RPM up to, high-temperature resistant materials
24000 RPM
RPM up to, stainless and acid-resistant steels
19000 RPM
RPM up to, steels up to 1,200 N/mm²
32000 RPM
Series
byly_HM_KUD_2111
Shaft-Ø
6 mm
Toothing
3 PLUS
Toothing
3 PLUS
Total length
45 mm
Ø
6 mm
Ø External metric
6 mm
Ø Shaft metric
6 mm
