Hand crank straight
DIN 469-250-B17-D Bore, handle rotatableGGG - Gusseisen (GGG)
Item-no.: 1203475Supplier number: DIN 469-250-B17-Dcustoms tariff number: 84879059EAN: 4045525259102
Quantity:
1 PiecePackable
Price and stock visible after login
Description
The hub bores d1 H7 are not provided for in the official standard sheet.
Attributes
Bore identification
B - Bore
Borehole d1
B 17
Borehole filtercolumn
17
Form
D - with swivelling handle
Form F
100
Length I
250
Material
GGG - Cast iron (GGG)
RoHS
Ja
Weight
1.500 kg
d2
48
h1
48
h2
21
h3
36
h3 ≈
36
h4 Form D
105.5
h4 ≈Form D
105.5
Ø Ball handle
32
