Hydraulic nut
HMV 45E SKF MaProItem-no.: 1385043Supplier number: HMV 45Ecustoms tariff number: 84122180EAN: 7316577014313
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.
Attributes
Connection thread
Tr 225x4
Kolbenaußendurchmesser
300 mm
Kolbenbreite
8 mm
Kolbenfläche
15200 mm²
Kolbeninnendurchmesser
227 mm
Maximaldruck
80 Mpa
Maximale Kolbenschiefstellung
9 mm
Maximum pressure
800 bar
Outer diameter
312 mm
Screw thread
ISO 2901-1977 tolerance class 7H
Weight
14,50 kg
Width
45 mm
