Hydraulic nut
HMV 47E SKF MaProItem-no.: 1385047Supplier number: HMV 47Ecustoms tariff number: 84122180EAN: 7316577106094
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.
Attributes
Connection thread
Tr 235x4
Kolbenaußendurchmesser
311 mm
Kolbenbreite
8 mm
Kolbenfläche
16200 mm²
Kolbeninnendurchmesser
237 mm
Maximaldruck
80 Mpa
Maximale Kolbenschiefstellung
10 mm
Maximum pressure
800 bar
Outer diameter
326 mm
Screw thread
ISO 2901-1977 tolerance class 7H
Weight
16 kg
Width
46 mm
