Hydraulic nut
HMV 77E SKF MaProItem-no.: 1385079Supplier number: HMV 77Ecustoms tariff number: 84122180EAN: 7316577106773
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Facilitates easy and quick application of the high drive-up forces required for mounting bearings on tapered seatings. The hydraulic nut can also be used for dismounting bearings mounted on either adapter or withdrawal sleeves.
Attributes
Connection thread
Tr 385x5
Kolbenaußendurchmesser
483 mm
Kolbenbreite
11 mm
Kolbenfläche
34700 mm²
Kolbeninnendurchmesser
387 mm
Maximaldruck
40 Mpa
Maximale Kolbenschiefstellung
16 mm
Maximum pressure
400 bar
Outer diameter
504 mm
Screw thread
ISO 2901-1977 tolerance class 7H
Weight
41 kg
Width
58 mm
