Clamping lever, adjustable, straight
GN 302-22-M3-10-SW blackItem-no.: 1396728Supplier number: 302-22-M3-10-SWEAN: 4045525499393
Quantity:
1 PiecePackable
Item available in 9 variants:
Price and stock visible after login
Description
Adjustable hand levers GN 302 have a straight lever, not inclined, being parallel to the clamping space. Adjustable hand levers are ideal whenever parts have to be clamped in a confined space or in a particular lever position. The centre insert is connected to the lever via serrations which can easily be disengaged. Pulling the lever, disengages the serrations and allowing it to be swivelled to the ideal clamping position. On releasing the lever the serrations automatically re-engage.
Attributes
Adjustable
True
Colour
SW - black, RAL 9005, textured matt
Connection thread d1
M 3
Connection thread form
A - with external thread
Handle body material
ZD - Zinc die casting
Handle length l1
22
RoHS
Ja
Thread length l2
10
Weight
0.013 kg
d3
8
d4
10.5
h1
18.5
h2
2
h3
16.5
h4 Rastweg
3
