Ratchet ring spanner, angled
SW8 mm L140 mm switchable Gedore 7 UR 8Item-no.: 1029335Supplier number: 7 UR 8EAN: 4010886889350
PU (Packaging): 5 PieceQuantity:
1 PiecePackable
Item available in 15 variants:
Price and stock visible after login
Description
With same size each end, UD-profile, High torque transfer, Chrome-vanadium steel 31CrV3, Non-glare look due to matt chrome-plating, locking insert and pawl manganese-phosphated, Hot forged, Jaw: ground precisely to exact nominal size for optimum contact areas, In combination with adaptor 7 RA or 7 RB (please order separately) the spanner 7 R can be used as a (bit) ratchet, Ring 13° offset from shaft, reversible, With combination ratchet spanner No. 7 R for ratchet loosening and fast tightening, Hollow profile comfortable to hold, Warp-resistant geometry with double T-girder effect
Attributes
Head height 1
7 mm
Head height 2
3,8 mm
Head width 1
17,5 mm
Head width 2
19,8 mm
Jaw position
15 °
Length (battery)
140 mm
Material
31CrV3
Net weight
0,037 kg
Return swivel angle
7 °
Ring angle
13 °
Ring profile
UNIT-DRIVE
Surface
chrome-plated
Teeth
52
Total height
13 mm
Total length
141 mm
Total width
20 mm
Version
switchable, ring side 13 °
Wrench width
8,0 mm
