Ratchet ring spanner flat
SW22 mm, L292 mm Gedore 7 R 22Item-no.: 1027701Supplier number: 7 R 22EAN: 4010886889244
PU (Packaging): 5 PieceQuantity:
1 PiecePackable
Item available in 20 variants:
Price and stock visible after login
Description
With same size each end, UD-Profile, High torque transfer, Chrome-vanadium steel 31CrV3, Non-glare look due to matt chrome-plating, locking insert and pawl manganese-phosphated, Hot forged, Jaw: ground precisely to exact nominal size for optimum contact areas, In combination with adaptor 7 RA or 7 RB (please order separately) the spanner 7 R can be used as a (bit) ratchet, Hollow profile comfortable to hold, Warp-resistant geometry with double T-girder effect, For ratchet loosening and fast tightening, Ring 13° offset from shaft, reversible
Attributes
Head height 1
13,3 mm
Head height 2
7,1 mm
Head width 1
42,5 mm
Head width 2
48 mm
Jaw position
15 °
Length (battery)
292 mm
Material
31CrV3
Net weight
0,319 kg
Return swivel angle
6 °
Ring profile
UNIT-DRIVE
Surface
chrome-plated
Teeth
60
Total height
14 mm
Total length
292 mm
Total width
49 mm
Version
straight
Wrench width
22,0 mm
