Circular saw blade
160x16x2.4 mm, 12 Bosch 2.608.640.784 Speedline WoodItem-no.: 1275697Supplier number: 2608640784customs tariff number: 82023900EAN: 3165140239950
Quantity:
1 PiecePackable
Price and stock visible after login
Description
The Speedline Wood Circular Saw Blade delivers fast rip and crosscuts in all types of wood. Its high-quality precision-ground carbide teeth make the blade robust enough for rapid cutting while its base blade made of dimensionally stable SK5 hardened steel (> 40 HRC) ensures accuracy. Furthermore, the blade´s expansion slots lower vibration during use, which dampens noise and reduces heat development. Use this saw blade in all types of wood and wooden materials. Speedline Wood Circular Saw Blade delivers fast rip and crosscuts in all types of wood
Attributes
Bohrung mm
16 mm
Borehole
16 mm
Clearance angle
15
Core sheet thickness (b2)
1.6 mm
Core sheet thickness (b2) mm
1,6 mm
Cutting angle
16 °
Cutting result
1
Cutting width (b1)
2.2 mm
Cutting width (b1) mm
2,2 mm
Cutting width (b1) mm / blade thickness (b2) mm
2.2/1.6
Freiwinkel ° β
15
Max. Rotationsgeschwindigkeit (U/min)
9500 U/min
Max. rotation speed
9500 U/min
Number of teeth
12
Outer diameter
160 mm
Outer diameter mm
160 mm
Spanwinkel ° α
16
Tooth form
ATB/FT
