Description
The Best for Laminate Circular Saw Blade is durable when cutting all kinds of laminate flooring. The blade´s Proteqtion coating prevents corrosion and delivers reliable cutting while reducing friction. Moreover, this coating keeps the blade cool, protecting it against corrosion. Its high performance and quality are also strengthened by the blade´s unique extra-hard Microteq teeth that are manufactured in-house by Bosch and consist of durable carbide grains. Additionally, it is specially designed with anti-vibration slots that significantly reduce vibration and noise to make precise cutting easy and comfortable. The Best for Laminate Circular Saw Blade features HLTCG (High-Low Triple Chip Ground) teeth, which make the blade robust for working even in highly abrasive materials such as laminate flooring.
Attributes
Bohrung mm
30 mm
Borehole
30 mm
Clearance angle
15
Core sheet thickness (b2)
1.8 mm
Core sheet thickness (b2) mm
1,8 mm
Cutting angle
5 °
Cutting result
4
Cutting width (b1)
2.5 mm
Cutting width (b1) mm
2,5 mm
Cutting width (b1) mm / blade thickness (b2) mm
2.5/1.8
Freiwinkel ° β
15
Max. Rotationsgeschwindigkeit (U/min)
8800 U/min
Max. rotation speed
8800 U/min
Number of teeth
60
Outer diameter
216 mm
Outer diameter mm
216 mm
Spanwinkel ° α
5
Tooth form
HLTCG
