Circular saw blade
225x30x2.6 mm, 48 Bosch 2.608.644.090 Expert for WoodItem-no.: 1275902Supplier number: 2608644090customs tariff number: 82023900EAN: 3165140796569
Quantity:
1 PiecePackable
Price and stock visible after login
Description
MicroteQ teeth (manufactured in-house) from high-density carbide combined with robust tooth shape ideal for universal use Depending on the number of teeth, different results can be achieved with all Expert for Wood Circular Saw Blades, which feature an ATB (Alternate Top Bevel) tooth geometry: when equipped with a high tooth count, the blade delivers clean cuts, whereas a low number of teeth guarantees solid and efficient cuts.
Attributes
Bohrung mm
30 mm
Borehole
30 mm
Clearance angle
15
Core sheet thickness (b2)
1.6 mm
Core sheet thickness (b2) mm
1,6 mm
Cutting angle
10 °
Cutting result
4
Cutting width (b1)
2.6 mm
Cutting width (b1) mm
2,6 mm
Cutting width (b1) mm / blade thickness (b2) mm
2.6/1.6
Freiwinkel ° β
15
Max. Rotationsgeschwindigkeit (U/min)
8400 U/min
Max. rotation speed
8400 U/min
NL/Durchmesser TKS
2/7/42
Number of teeth
48
Outer diameter
225 mm
Outer diameter mm
225 mm
Spanwinkel ° α
10
Tooth form
WZ
