Bosch

Circular saw blade

250x30x3.2 mm, 80 Bosch 2.608.640.516 Multi Material
Item-no.: 1043689Supplier number: 2608640516customs tariff number: 82023900EAN: 3165140193061

Quantity: ​​ 1 PiecePackable
Short-term Sourcing

Description
The Multi Material Circular Saw Blade delivers powerful cuts in a wide range of materials. Its high-quality precision-ground carbide teeth make the blade robust enough for cutting various materials, while its base blade made of dimensionally stable SK5 hardened steel (> 40 HRC) ensures accuracy. Furthermore, the blade's expansion slots lower vibration during use, which dampens noise and reduces heat development. Use this saw blade in non-ferrous metals, aluminium, plastics, epoxy and wood. The HLTCG (High-Low Triple Chip Ground) teeth make the Multi Material Circular Saw Blade robust for working with abrasive materials.
Attributes
Bohrung mm
30 mm
Borehole
30 mm
Clearance angle
18
Core sheet thickness (b2)
2.5 mm
Core sheet thickness (b2) mm
2,5 mm
Cutting angle
-5 °
Cutting result
3
Cutting width (b1)
3.2 mm
Cutting width (b1) mm
3,2 mm
Cutting width (b1) mm / blade thickness (b2) mm
3.2/2.5
Freiwinkel ° β
18
Max. Rotationsgeschwindigkeit (U/min)
6000 U/min
Max. rotation speed
6000 U/min
NL/Durchmesser TKS
7/42
Number of teeth
80
Outer diameter
250 mm
Outer diameter mm
250 mm
Spanwinkel ° α
-5
Tooth form
HLTCG
