Circular saw blade
500x30x3.8 mm, 36, SB3 Bosch 2.608.640.705 Construct WoodItem-no.: 1275689Supplier number: 2608640705customs tariff number: 82023900EAN: 3165140194846
Quantity:
1 PiecePackable
Price and stock visible after login
Description
The Construct Wood Circular Saw Blade is durable when cutting construction site timber with nails and concrete residues. Its high-quality precision-ground carbide teeth make the blade robust for tough applications. Moreover, its expansion slots lower vibration during use, which dampens noise and reduces heat development. The blade features a base blade made of dimensionally stable SK5 hardened steel (> 40 HRC) which ensures accuracy. Use this saw blade in construction timber with nails and concrete residues. Construct Wood Circular Saw Blade is durable when cutting construction site timber with nails and concrete residues
Attributes
Bohrung mm
30 mm
Borehole
30 mm
Clearance angle
10
Core sheet thickness (b2)
2.8 mm
Core sheet thickness (b2) mm
2,8 mm
Cutting angle
15 °
Cutting result
1
Cutting width (b1)
3.8 mm
Cutting width (b1) mm
3,8 mm
Cutting width (b1) mm / blade thickness (b2) mm
3.8/2.8
Freiwinkel ° β
10
Max. Rotationsgeschwindigkeit (U/min)
3000 U/min
Max. rotation speed
3000 U/min
Number of teeth
36
Outer diameter
500 mm
Outer diameter mm
500 mm
Spanwinkel ° α
15
Tooth form
WZ
