Bosch

Circular saw blade Exp. Laminated Panel

160x1.8/1.2x20, 48 teeth Bosch 2.608.644.548
Item-no.: 1438469Supplier number: 2608644548customs tariff number: 82023100EAN: 3165140957786

Quantity: ​​ 1 PiecePackable
Short-term Sourcing

Description
The Expert for Laminated Panel Circular Saw Blade maximises the cordless saw´s battery runtime. Its extra-thin kerf reduces friction and material removal, consuming less power for effortlessly smooth sawing. MicroteQ carbide teeth ensure high durability and a superior performance in laminated panels. It is ideal for cutting in raw, veneered or laminated chipboard, acoustic panels, and single- and double-coated abrasive panels. The Expert for Laminated Panel Circular Saw Blade features MicroteQ teeth consisting of extra-fine and durable carbide grains from Bosch in-house production, ensuring superior lifetime. The blade´s anti-corrosive ProteQtion coating reduces friction, prevents rust and provides highly durable cutting performance.
Attributes
Bohrung mm
20 mm
Borehole
20 mm
Borehole with reducer ring
15.875 mm
Clearance angle
15
Core sheet thickness (b2)
1.2 mm
Core sheet thickness (b2) mm
1,2 mm
Cutting angle
-5 °
Cutting result
4
Cutting width (b1)
1.8 mm
Cutting width (b1) mm
1,8 mm
Cutting width (b1) mm / blade thickness (b2) mm
1.8/1.2
Freiwinkel ° β
15
Max. Rotationsgeschwindigkeit (U/min)
8500 U/min
Max. rotation speed
8500 U/min
Number of teeth
48
Outer diameter
160 mm
Outer diameter mm
160 mm
Spanwinkel ° α
-5
Tooth form
WZ
