Universal joint with plain bearing
DIN 808-28-K14-60-EG Simple, bore and grooveST - Stahl
ST - Steel
Item-no.: 1213584Supplier number: DIN 808-28-K14-60-EGcustoms tariff number: 84831050EAN: 4045525377851
Quantity:
1 PiecePackable
Price and stock visible after login
Description
The permissible r.p.m. of universal joints with friction bearing DIN 808 is to a large extent dependent on the type of application such as load, duration, angular disposition as well as lubrication . For over 1000 r.p.m. universal joints with needle bearing should be used For continuous use ample lubrication is essential. This achieved by fitting the joint with a grease filled gaiter GN 808.1.
Attributes
Bore labelling
K - with hub groove DIN 6885-1 P9
Borehole d2
14
Borehole filtercolumn
B 14
Form
EG - single, plain bearing
Length l1 (Form EG)
60
Material
ST - Steel
Outer diameter d1
28
RoHS
Ja
Weight
0.185 kg
l3
30
t max. Einbaulänge der Welle
13
t max. installation length of the shaft
13
