Charger
GAL 3680 CV Bosch 1.600.A00.4ZSItem-no.: 1270427Supplier number: 1600A004ZScustoms tariff number: 85044060EAN: 3165140818421
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Charger GAL 3680 CV, The multi-volt quick charger for all Li-Ion batteries from 14.4 to 36 volts, 100% faster charging of the batteries (compared to AL 3640 CV), Quick-charge mode: 4.0 Ah battery is ready to use with 80% of its capacity after only 25 mins, Active Air Cooling for longer lifetime of the batteries, Cardboard box, Quick charger GAL 3680 CV (2 607 225 899)
Attributes
Battery charging voltage
14.4 - 36 V
Battery charging voltage, from
14.4 V
Battery charging voltage, to
36 V
Charge current
8.0 A
Charging time ProCORE18V 12.0Ah (80 %/100 %) approx.
113/126 min
Charging time ProCORE18V 4.0Ah (80 %/100 %) approx.
32/51 min
Charging time ProCORE18V 8.0Ah (80 %/100 %) approx.
68/79 min
Charging time for ProCORE18V 12.0Ah (100 %) approx.
126
Charging time for ProCORE18V 12.0Ah (80 %) approx.
113
Charging time for ProCORE18V 4.0Ah (100 %) approx.
51
Charging time for ProCORE18V 4.0Ah (80 %) approx.
32
Charging time for ProCORE18V 8.0Ah (100 %) approx.
79
Charging time for ProCORE18V 8.0Ah (80 %) approx.
68
Charging time for battery capacity 1.5 Ah (100 %) approx.
25
Charging time for battery capacity 1.5 Ah (80 %) approx.
10
Charging time for battery capacity 1.5 Ah (80 %/100 %) approx.
10/25 min
Charging time for battery capacity 2.0 Ah (100 %) approx.
30
Charging time for battery capacity 2.0 Ah (80 %) approx.
15
Charging time for battery capacity 2.0 Ah (80%/100%) approx.
15/30 min
Charging time for battery capacity 2.0 Ah (80%/100%) approx.
15/30 min
Charging time for battery capacity 3.0 Ah (100 %) approx.
35
Charging time for battery capacity 3.0 Ah (80 %) approx.
20
Charging time for battery capacity 3.0 Ah (80 %/100 %) approx.
20/35 min
Charging time for battery capacity 4.0 Ah (100 %) approx.
35
Charging time for battery capacity 4.0 Ah (80 %) approx.
25
Charging time for battery capacity 4.0 Ah (80%/100%) approx.
25/35 min
Charging time for battery capacity 5.0 Ah (100 %) approx.
45
Charging time for battery capacity 5.0 Ah (80 %) approx.
35
Charging time for battery capacity 5.0 Ah (80 %) approx.
35
Charging time for battery capacity 5.0 Ah (80%/100%) approx.
35/45 min
Charging time for battery capacity 5.0 Ah (80%/100%) approx.
35/45 min
Charging time for battery capacity 6.0 Ah (100 %) approx.
55
Charging time for battery capacity 6.0 Ah (100 %) approx.
55
Charging time for battery capacity 6.0 Ah (80 %) approx.
35
Charging time for battery capacity 6.0 Ah (80 %) approx.
35
Charging time for battery capacity 6.0 Ah (80%/100%) approx.
35/55 min
Charging time for battery capacity 6.0 Ah (80%/100%) approx.
35/55 min
Charging time for battery capacity 6.3 Ah (100 %) approx.
55
Charging time for battery capacity 6.3 Ah (80 %) approx.
41
Charging time for battery capacity 6.3 Ah (80 %/100 %) approx.
41/55 min
Ladezeit bei Akkukapazität 1,5 Ah (100 %) ca.
25
Ladezeit bei Akkukapazität 1,5 Ah (80 %) ca.
10
Ladezeit bei Akkukapazität 1,5 Ah (80 %/100 %) ca.
10/25 min
Ladezeit bei Akkukapazität 2,0 Ah (100 %) ca.
30
Ladezeit bei Akkukapazität 2,0 Ah (80 %) ca.
15
Ladezeit bei Akkukapazität 3,0 Ah (100 %) ca.
35
Ladezeit bei Akkukapazität 3,0 Ah (80 %) ca.
20
Ladezeit bei Akkukapazität 3,0 Ah (80 %/100 %) ca.
20/35 min
Ladezeit bei Akkukapazität 4,0 Ah (100 %) ca.
35
Ladezeit bei Akkukapazität 4,0 Ah (80 %) ca.
25
Ladezeit bei Akkukapazität 4,0 Ah (80%/100%) ca.
25/35 min
Ladezeit bei Akkukapazität 5,0 Ah (100 %) ca.
45
Ladezeit bei Akkukapazität 6,3 Ah (100 %) ca.
55
Ladezeit bei Akkukapazität 6,3 Ah (80 %) ca.
41
Ladezeit bei Akkukapazität 6,3 Ah (80 %/100 %) ca.
41/55 min
Packaging dimensions (width x length x height)
140 x 250 x 96 mm
Weight
1 kg
