Magnetspule
30 mm x Ø 8 mm,Anschluss f.Gerätestecker Bauform A, 24 V AC, 50/60 Hz, 3,5 VAItem-no.: 1732837Supplier number: W0210011100EAN: 4047322770156
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Solenoid, 30 mm x Ø 8 mm, connection for plug connector type A, 24 V AC, 50/60 Hz, 3,5 VA.
Attributes
Anschlüsse
DIN 43650 Form A - ISO 4400
Duty cycle
100 %
Insulation class
F155
Max. Spulentemperatur bei 100% ED
70 °C at 20 °C ambient temperature
Protection class
IP 65 EN 60529 with correctly fitted plug including seal
Rated voltage
24 V 50/60 Hz
Spannungstoleranz
-10% to +10%
