Digital inclinometer
GIM 60 L Bosch 0.601.076.900Item-no.: 1269791Supplier number: 0601076900EAN: 3165140803243
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Digital Inclinometer GIM 60 L, Laser-accurate incline transfer over longer distances, Integrated point laser for incline measurement up to a distance of 30 m, Strong magnets and two straps for securely fastening the instrument to workpieces, Incline mechanism for fine adjustment on uneven surfaces, Protective Bag, 4 x 1.5 V LR6 battery (AA)
Attributes
Laser class
2
Laser range
30 m
Laser type
650 nm, < 1 mW
Length (battery)
60 cm
Levelling accuracy laser
± 0,5 mm/m
Measuring accuracy electronics 0°/90°
± 0.05 °
Measuring accuracy electronics at 1 - 89°
± 0.1 °
Measuring range
0 – 360° (4 x 90°)
Messgenauigkeit Elektronik bei 1 – 89°
± 0,1°
Stromversorgung Neigungsmessung
1 x 9 V-6LR61 + 2 x 1,5 V LR03
Tripod mount
1/4"
Units of measurement
°, %, mm/m
Weight approx.
0,91 kg
Work area (laser)
30 m
