PTFE composite socket
PCM 050705 E lead-free, SKFPTFE-Verbundwerkstoff
Item-no.: 1305766Supplier number: PCM 050705 Ecustoms tariff number: 84833080EAN: 7316571894171
PU (Packaging): 50 PieceQuantity:
50 PiecePackable
Price and stock visible after login
Description
SKF PTFE composite straight (cylindrical) bushings are suitable for oscillating, rotating and linear movements, and can accommodate radial loads. Despite their thin-walled design, they can accommodate heavy loads. They also provide good heat dissipation, therefore enabling relatively high sliding velocities.
Attributes
Borehole diameter
5 mm
Dynamische Tragzahl
2 kN
Material
PTFE-Verbundwerkstoff
Outer diameter
7 mm
Statische Tragzahl
6.3 kN
Width
5 mm
