Polyethylene hose
Hose Ø 8x1 mm, blue RO100Item-no.: 1462875Supplier number: 259.02-B-100-V2EAN: 4047322687591
PU (Roll): 100 MeterQuantity:
100 MeterPackable
Item available in 56 variants:
Price and stock visible after login
Description
Polyethylene hose (LD-PE), Temperature -40 °C to 60 °C, Hose ø 8x1 mm, PN at 23 °C max. 8 bar, blue, Roll of 100 m. Low-priced, calibrated hose for use with screw fittings. With its soft and flexible character, combined with relatively high strengths and good resistance to stress cracking, this hose is ideal for use in the following types of application: - Flexible pneumatic lines in the low-pressure range, providing no special resistance to greases, oils or other hydrocarbons is required. - Compressed air control lines. - Vacuum lines (suitable for vacuum up to 10 x 8 mm). - Supply lines of all kinds.
Attributes
Colour
blue
Hose-Ø inside
6 mm
Hose-Ø outer
8 mm
Material
Polyethylene (LD-PE)
Max. operating pressure at 23 °C
8 bar
Riegler article number
194249
Roll length
100 m
Temperature range max.
60 °C
Temperature range min.
-10 °C
Wall thickness
1 mm
