Reducing nipple, short
Male 1/2" x female 1/4", L 15.5 mm stainless steelItem-no.: 1226766Supplier number: 251.07-EScustoms tariff number: 73072910EAN: 4047322063470
Quantity:
1 PiecePackable
Item available in 12 variants:
Price and stock visible after login
Description
Reducing nipple, short, G 1/2 o., G 1/4 i. AF 22 Stainless steel 1.4571, Max. working pressure 60 bar, Max. operating temp. 150 °C.
Attributes
External thread
G 1/2
Gewinde 1
G 1/4 IG
Gewinde 2
G 1/2 AG
Internal thread
G 1/4
L1
15,5 mm
L2
11,5 mm
Material
Stainless steel 1.4571
Operating temperature max.
150 °C
Riegler article number
111626
SW
22 mm
Working pressure max.
60 bar
