Reducing nipple short G 1 a. G 3/4 i.

SW 38 Brass vern.

Item-no.: 1373270Supplier number: MSN251K0134customs tariff number: 74122000EAN: 4047322489669

Quantity:  1 PiecePackable

Item available in 26 variants:

Description

Reducing nipple short type, G 1 o., G 3/4 i., AF 38, nickel-plated brass, Max. working pressure 25 bar, Max. operating temp. 150°C. Suitable for air, water, oil, steam, etc.

Attributes

External thread

G 1

Gewinde 1

G 3/4 IG

Gewinde 2

G 1 AG

Internal thread

G 3/4

19,0 mm

13,0 mm

Material

Nickel-plated brass CW614N (galvanised nickel-plated)

Operating temperature max.

150 °C

Riegler article number

134720

38 mm

Working pressure max.

25 bar
