Combination spanner, angled
SW25 mm L290 mm Form A Gedore 7 25Item-no.: 1027792Supplier number: 7 25customs tariff number: 82041100EAN: 4010886609231
PU (Packaging): 10 PieceQuantity:
1 PiecePackable
Item available in 25 variants:
Price and stock visible after login
Description
Acc. to DIN 3113, Form A, ISO 3318, ISO 7738, Chrome-vanadium steel 31CrV3, chrome-plated, Carefully forged and professionally machined, Slim jaw and jaw walls make this spanner lighter overall, Jaw: ground precisely to exact nominal size for optimum contact areas, Ring: 15° offset from shaft, with UD profile for gentle transmission of force, Overloading indicated by deformation, Secure grip thanks to hollow shaft - very ergonomic and handy, Glare-free look due to matt chrome, Designed for universal use, Top-grade industrial quality for the hardest of continuous use, Size 3 to 5.5 with hexagonal ring, from 6mm with UD profile, * not standardised
Attributes
Head height 1
14,5 mm
Head height 2
8,2 mm
Head width 1
36 mm
Head width 2
54,5 mm
Jaw position 1
15 °
Length (battery)
290 mm
Material
CV steel
Net weight
0,295 kg
Norm
DIN 3113 Form A, ISO 3318, ISO 7738
Ring angle
15 °
Ring profile
UNIT-DRIVE
Surface
chrome-plated
Total height
24 mm
Total length
290 mm
Total width
55 mm
Wrench width
25 mm
Wrench width 1
25 mm
