Description
Drawers with one-hand operation and safety lock, Load capacity per drawer 40 kg, lower heavy-duty drawer 60 kg, Central locking with cylinder lock, Static load capacity 1000 kg, in mobile operation 500 kg, Dimensions: H 985 x W 1100 x D 550 mm, Ball-bearing guide rails, Can be individually equipped with lengthwise and crosswise dividers (can be ordered individually), Load capacity per drawer 40 kg, lower heavy-duty drawer 60 kg (not with No. 1504 1000), GEDORE High-performance chassis: Total load capacity 1000 kg, 750 kg when mobile, 2 roller-bearing GEDORE high-performance wheels (fixed castors Ø 200 mm), 2 ball-bearing mounted GEDORE smooth-running wheels (swivel castors Ø 125 mm), both with total brakes, The GEDORE trapezoidal axle construction secures smooth running, manoeuvrability and track-keeping also in case of maximum loads, Parallel vice: Sturdy forged design, Jaws and anvil plate induction hardened, Protected vice spindle and adjustable guide, The GEDORE trapezoidal axle construction secures smooth running, manoeuvrability and track-keeping also in case of maximum loads, 4 distance modules No. 1500 ED-70 K, Length- (LT) and crosswise (QT) dividers from zinc-plated sheet steel (can be ordered individually), Options: Can be equipped with GEDORE tool modules (1500 ES/1500 CT), Can be extended with rear panel No. R 1504 L or rear panel No. RT 1504 L, Further drawer combinations on request, Special colours and designs available on request, Delivery without tools and accessories







Attributes
1000 V isoliert
Nein
Ausführung
Rollwerkbank mit 7 Schubladen und Schraubstock
Colour
GEDORE blue, RAL 5017
Countertop dimension
1100 x 550 x 30 mm
Countertop thickness
30 mm
Dimension (L x W x H)
985 x 1.100 x 550 mm
Dynamic load capacity
750 kg
Einzelauszugssperre
Nein
Fixed castor diameter (2x)
200
Inhalt
1 Stück
Load capacity heavy duty drawer
60 kg
Load capacity per drawer
40 kg
Lockable
Ja
Material
Sheet steel
Net weight
112480 g
Nominal height
985 mm
Nominal length
630 mm
Nominal width
1100 mm
Number of cabinets
1
Number of cross dividers
2
Number of drawers
7
Number of length dividers
3
Number of shelves
1
Number of wheels
4
Schubladentyp
5x Typ 1, H. = 67 mm1x Typ 2, H. = 137 mm1x Typ 3, H. = 207 mm
Static load capacity
1000 kg
Surface
Powder-coated
Swivel castor diameter with brakes (2x)
125
Total height
985 mm
Total length
550 mm
Total width
1100 mm
VDE zertifiziert
Nein
Working height
985
