Gear hub
GN 750-50-K16-MST - Stahl
Item-no.: 1394234Supplier number: 750-50-K16-Mcustoms tariff number: 84879059EAN: 4045525371088
Quantity:
1 PiecePackable
Price and stock visible after login
Description
The cover hides fasteners (see assembly instructions) as well as protruding or recessed shafts and provides a printing facility for any symbol or logo. On assembly, the cover is pushed in by hand and can be removed with a screw driver via a suitable slot.
Attributes
Bore identification
K - with hub groove DIN 6885-1 P9
Filtercolumn
B 14
Filtercolumn1
B 16
Form
M - Lid with marking
Length l
130
Material
ST - Steel
RoHS
Ja
Switch lever diameter d1
50
Weight
0.402 kg
d2
16
d3
40
d4
37.5
d5
23
d6
11
h1
28
h2
22
h3
3.8
h4
63
h4 ≈
63
