Hazet

Impact wrench compressed air

Hazet 9013MTT
Item-no.: 1668428Supplier number: 9013MTTEAN: 4000896258062

Quantity: ​​ 1 PiecePackable
Promotional item
Short-term Sourcing

Description
Application: - Operation of tight-fitting screw connections in narrow installation spaces with low workload in daily operation · Loosening torque maximum [Nm]: 1890 Nm · Exhaust air is guided through the handle downwards · Reduced vibrations · Easy handling · Reduced workload due to low weight and handy dimensions · Long service life and high efficiency in industrial and automotive applications · Compact design, optimised for work in confined spaces · 20 mm (3⁄4″) impact wrench in 12.5 mm (1⁄2″) housing size · HAZET Twin Turbo technology – high torques with compact design · 8-blade air motor with 25% higher impact performance ensures maximum torque · Easy to use · Powerful twin hammer mechanism · Air connection inlet: Inside thread 12.91 mm (1/4″) · Coupler plug: Nominal size 7.2 (included) · Recommended torque: 900 Nm · Hose diameter (recommended): 10 mm · Working pressure (bar): 6.3 · Sound power level: 110.3 db(A) Lp W · Vibration acceleration: 11.39 m/s2 · Loosening torque (max) determined with screw size M: 26 · Forward and reverse: three-stage (forward), single-stage (reverse) · Cold insulated handle · Output: 3/4 inch (20 mm) square, solid · Net weight: 1.7 kg · For impact operation · Tightening torque max Nm: 1300 Nm · Loosening torque maximum [Nm]: 1890 Nm · Sound pressure level: 99.3 dB(A) Lp A · Revolutions per minute: 8000 · Air requirement: 150 l/min (2.5 l/sec).
Piktogramm
Attributes
Air connection inlet
Internal thread 12.91 mm (1/4″)
Air requirement [l/min]
150 l/min
Air requirement [l/sec]
2.5 l/sec
Anzugsmoment maximal [Nm]
1300 Nm
Anzugsmoment maximal [lbf.ft]
958.83 lbf.ft
Clockwise/anticlockwise rotation
three-stage (clockwise rotation), single-stage (anti-clockwise rotation)
Coupling plug
Nominal diameter 7.2 (included)
Handle
Cold insulating handle
Hose diameter (recommended)
10 mm
Impact mechanism (type)
High-performance double hammer impact mechanism
Loosening moment (max) determined with screw size M
26 M
Lösemoment maximal [Nm]
1890 Nm
Net weight (g)
1700 g
Net weight (kg)
1.7 kg
Operating pressure (bar)
6.3 bar
Output
3/4 inch (20 mm) square solid
Recommended torque
900 Nm
Revolutions/minute (maximum)
8000 upm
Sound power level
110.3 db(A) Lp W
Sound pressure level
99.3 dB(A) Lp A
