Riegler

Standard pressure gauge

AG 1/4", 0-2.5 bar, D 50 mm Steel housing, rear connection
Item-no.: 1116571Supplier number: 203customs tariff number: 90262040EAN: 4047322033879

Quantity: ​​ 1 PiecePackable
Item available in 38 variants:
Short-term Sourcing

Description
Standard pressure gauge, Single scale bar, Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range 0 - 2.5 bar, Ø 50. Bourdon-tube pressure gauge in standard design. Suitable for gaseous or liquid media which do not corrode copper alloy, do not have high viscosity and do not crystallise.
Attributes
Ambient temperature max.
60 °C
Ambient temperature min.
-20 °C
Connection
G 1/4
Connection position
Rear, centric
Diameter
50 mm
Housing
Sheet steel
Lower / upper measuring range limit
Overpressure
Material process connection
Copper alloy
Measuring element
Copper alloy
Measuring range max. bar
2,5
Measuring range min. bar
0
Medium temperature max.
60 °C
Medium temperature min.
-20 °C
Pointer movement
Copper alloy
Quality class
1.6
Riegler article number
101823
Scale graduation in the bar range
0,1 bar
Screw thread
G 1/4 AG
Type
111.12
Viewing window
Plastic
