Standard pressure gauge, pressure line
AG 1/4", D63mm, 0-6 bar, -20°C - 60°C Sheet steel, rear connectionItem-no.: 1247652Supplier number: 216-DEcustoms tariff number: 90262040EAN: 4047322175968
Quantity:
1 PiecePackable
Item available in 23 variants:
Price and stock visible after login
Description
Standard pressure gauge »pressure line« Connection, rear, centric, G 1/4, Goods class 1.6, Measurement range 0-6 bar/85 psi, Ø 63. Low-priced series of standard pressure gauges available in all popular diameters with the most frequently requested measuring ranges. Suitable for gaseous or liquid media which do not corrode copper alloy, do not have high viscosity and do not crystallise.
Attributes
Ambient temperature max.
60 °C
Ambient temperature min.
-20 °C
Connection
G 1/4
Connection position
Rear, centric
Diameter
63 mm
Housing
Sheet steel
Lower / upper measuring range limit
Overpressure
Material process connection
Copper alloy
Measuring element
Copper alloy
Measuring range max. bar
6
Measuring range min. bar
0
Medium temperature max.
60 °C
Medium temperature min.
-20 °C
Pointer movement
Copper alloy
Quality class
1.6
Riegler article number
115503
Scale graduation in the bar range
0,2 bar
Screw thread
G 1/4 AG
Version
Bourdon tube pressure gauge
Viewing window
Plastic
