Ganter

Stellungsanzeiger Edelstahl-Hohlwelle

GN 954.2-002.0-FN-L-OR
KT - Plastic
Item-no.: 1486431Supplier number: 954.2-002.0-FN-L-OREAN: 4045525765795
Quantity: ​​ 1 PiecePackable​
Item available in 312 variants:
Short-term Sourcing
Description
Position indicators GN 954.2 are fitted with a direct drive counter with digital read out. Both housing sections are ultrasonically welded, making the housing very tightly seated, stable and compact. The foam rubber seal prevents the transmission of vibration to the counter and also acts as a seal.
Attributes
Colour
OR - orange, RAL 2004
Corresponds to thread pitch
2
Counter
002.0
Display after 1 spindle revolution
002.0
Form
L - digits increasing with anti-clockwise rotation
Installation position
FN - straight, top
Material
KT - Plastic
RoHS
Ja
Weight
0.043 kg
max.Drehzahl / min.
1250
