Position indicator orange
GN 954-006.0-AN-R-OR Elesa CE.84265KT - Kunststoff
Item-no.: 1216678Supplier number: 954-006.0-AN-R-ORcustoms tariff number: 90318080EAN: 4045525416697
Quantity:
1 PiecePackable
Price and stock visible after login
Description
Position indicators GN 954 are fitted with a direct drive counter with digital read out. The two housing parts are ultra-sonically welded, thus the housing is particularly sturdy and compact. The foam rubber seal prevents the transmission of vibration to the counter and also acts as a seal.
Attributes
Anzeigeposition
AN - diagonal, top
Colour
OR - orange, RAL 2004, glossy
Corresponds to thread pitch
6
Counter
006.0
Display after 1 spindle revolution
006.0
Form
R - digits increasing with clockwise rotation
Installation position
AN - diagonal, top
Material
KT - Plastic
Max. speed/min.
415
RoHS
Ja
Weight
0.043 kg
Zählrichtung
R - Numerical value increasing with clockwise rotation
Zählwerk (mit einer Dezimalstelle)
006.0
max.Drehzahl / min.
415
