Step drill
6.0-30.5 mm HSS-TiN Ruko 101098THSS
Item-no.: 1014355Supplier number: 101098TEAN: 4007140143389
Quantity:
1 PiecePackable
Price and stock visible after login
Description
The CBN ground and spiral flutes guarantee quiet running and high cutting performance. Especially the chip flow is optimized, so even long, non-breaking chips will be removed easily. The optimized chip flow protects the cutting edges and reduces built-up edges and cold weld marks. The cone makes it easier to withdraw the tool from the material.
Attributes
Coat
TiN
Cutting direction
right-hand cutting
Drilling area
6,0 - 30,5 mm
Length (battery)
80 mm
Material
HSS
Number of cutting edges
2
Number of steps
9
Series
RUKO008101
Shaft
Trihedral shank
Shaft diameter
10 mm
Size no.
8
Step angle
90°
Tip angle
118°
Tolerance
Factory standard
