Washer
U 212 for axial deep groove ball bearings, SKFRolling bearing steel
Item-no.: 1278593Supplier number: U 212customs tariff number: 84829900EAN: 7316577009340
Quantity:
1 Piece
=
1 PackagingPackable
Price and stock visible after login
Description
Sphered seat washers are used together with thrust ball bearings with sphered housing washers when the bearing is fitted into a machine component manufactured with a flat surface. The seat washers are supplied as separate components. Depending on bearing series, they have the basic designation U 2, U 3 or U 4 followed by a two-digit number, which identifies the size, e.g. sphered seat washer U 320 for bearing 53320.
Attributes
Borehole diameter
78 mm
Coat
Ohne
Höhe
9 mm
Material
Rolling bearing steel
Outer diameter
100 mm
Thickness
9 mm
