Description
Angle Grinder GWS 22-230 P, The GWS 22-230 P Professional angle grinder is characterised by the synergy between its robustness and firm performance capability, enhanced even further by its PROtection switch for increased user protection. Strong cutting results are supplied by the high material removal rate that the new 2,200-W motor provides. With the heating of the motor system lowered overall and contact between the motor and the carbon brushes enhanced, the GWS 22-230 P’s lifetime has improved. Automatically turning the angle grinder off when released, the PROtection switch offers enhanced user protection. This angle grinder is ideal for versatile cutting tasks in metal as well as stone. It is compatible with Bosch’s GDE 230 FC-S dust attachment. Protective cover (1 619 P15 668), Vibration Control auxiliary handle (2 608 900 001), Two-hole spanner (1 607 950 048), Backing flange (1 605 703 099), Locking nut (1 603 340 040), Cardboard box
Attributes
Disc Ø
230 mm
Grinding spindle thread
M14
Idle speed
6500 min-1
Leerlaufdrehzahl, bis zu
6.500 min-1
Measurement uncertainty k (sanding with sanding sheet)
1.5 m/s²
Measurement uncertainty k (surface grinding (roughing ))
1.5 m/s²
Nominal input power
2200 W
Pot brush, Ø
100 mm
Rubber sanding disc, Ø
230 mm
Vibration emission value ah [sanding with sanding sheet]
2.5 m/s²
Vibration emission value ah [surface grinding (roughing)]
5.5 m/s²
Voltage, electrical
230 V
Weight
5.5 kg
