Description
Angle Grinder GWS 24-230 PZ, The powerful GWS 24-230 PZ Professional angle grinder comes with the revolutionary CYCLON TECH dust protection system and safety features for increased user protection. A tough 2,400 W motor delivers robust cutting and grinding. The built-in CYCLON TECH dust protection system prolongs lifespan by collecting up to 90% of dust into the angle grinder. Worker comfort and user protection are improved by a smoother motor operation and an anti-vibration auxiliary handle. This angle grinder is ideal for cutting metal, grinding stone, and for application on a variety of materials. It is compatible with Bosch’s GDE 230 FC-S dust attachment. The GWS 24-230 PZ Professional offers a PROtection switch for enhanced user protection. Two-hole spanner (1 607 950 061), Backing flange (spare part number 2 605 703 014), Locking nut (1 603 345 043), Cardboard box, Protective cover (1 619 P15 622), Auxiliary handle (1 602 025 030)
Attributes
Abgabeleistung
2.400 W
Bemessungs-Leerlaufdrehzahl
6500 min-1
Bohrung, Ø
22,23 mm
Disc Ø
230 mm
Grinding spindle thread
M14
Idle speed
6500 min-1
Idle speed, up to
6500 min-1
Leerlaufdrehzahl, von
5.200 min-1
Main handle
Bar handle
Measurement uncertainty k (sanding with sanding sheet)
1.5 m/s²
Measurement uncertainty k (surface grinding (roughing ))
1.5 m/s²
Nominal input power
2400 W
Packaging dimensions (width x length x height)
167 x 550 x 139 mm
Pot disc, Ø
140 mm
Rubber sanding disc, Ø
180 mm
Schleiftopf, Ø
110 mm
Spannung, elektrisch
230 V
Spannungsbereich
220 – 240 V
Tool dimensions (length)
530 mm
Topfbürste, Ø
100 mm
Vibration emission value ah [sanding with sanding sheet]
3.0 m/s²
Vibration emission value ah [surface grinding (roughing)]
6.5 m/s²
Weight
5.9 kg
Werkzeugabmessungen (Breite)
335 mm
Werkzeugabmessungen (Höhe)
138 mm
X-LOCK
Nein
