Feed wheel with hole
GN 736-52-B10-A Anodised aluminium SW, without handleAL - Aluminium
Item-no.: 1212431Supplier number: 736-52-B10-AEAN: 4045525364561
Quantity:
1 PiecePackable
Item available in 12 variants:
Price and stock visible after login
Description
Control handwheels GN 736 are used for setting operations with low torque. Coarse setting is made by means of the cylindrical handle (fingertip grip) followed by fine setting using the knurled rim of the handwheel.
Attributes
Bohrungskennzeichen
B - ohne Nabennut
Bore labelling
B - without hub groove
Borehole diameter d2
10
Form
A - without handle
Handwheel diameter d1
52
L1
23
L2
17
Material
AL - Aluminium
R
15.5
RoHS
Ja
Weight
0.056 kg
Zylinderknopf
13
b
13
d3
22
d4
37
d5
39.5
h
3.8
l3
19
l3 ≈
19
