Beschrijving
Impact Wrench GDR 18V-220 C, For smooth fastening of screws in wood and sheet metal, you need a tool that combines power with control. The GDR 18V-220 C Professional with ¼” hex drive is a high-torque, compact impact driver with additional features. With a head length of 113 mm, it is easier to handle especially when working in tight spots. Thanks to a powerful brushless motor with up to 3,400 RPM, three-speed settings, and a high torque of 220 Nm, you will get your work done faster and with more control. The tool’s adjustable screw modes ensure controlled application to prevent broken screwheads and damaged work pieces by slowing down (A) or shutting off (B) the impact driver. Additional modes can be accessed and adapted via the Bosch Toolbox App. You only need one hand to insert bits – just push the bit in to lock it. The double ball bearing ensures a firm hold of the bit and increases precision. With its two LED lights, one at the head and one at the foot of the driver, you get best-in-class workplace illumination. The tool’s all-metal gear housing is what professionals ask for. The tool has a status indicator and a belt clip. It is compatible with the Bosch Professional 18V System and with the multi-brand battery alliance AMPShare. Use this powerful and compact impact driver for top results on HVAC projects, electrical work, or carpentry. Cardboard box, 1 x belt clip, 1 x bit holder
Specificaties
Aantal slagen
4000 bpm
Aantal slagen (1e fase)
0-1500 bpm
Aantal slagen (2e fase)
0-3400 bpm
Aantal slagen (3e fase)
0-4000 bpm
Accuspanning
18.0 V
Draaimoment, max.
220 Nm
Draaimomentinstelbereik, max. 1e fase
100 Nm
Draaimomentinstelbereik, max. 2e fase
140 Nm
Draaimomentinstelbereik, max. 3e fase
220 Nm
Draaimomentinstelbereik, min. 1e fase
0 Nm
Draaimomentinstelbereik, min. 2e fase
0 Nm
Draaimomentinstelbereik, min. 3e fase
0 Nm
Draaimomentinstelbereik, min./max. 1e fase
0/100 Nm
Draaimomentinstelbereik, min./max. 2e fase
0/140 Nm
Draaimomentinstelbereik, min./max. 3e fase
0/220 Nm
Draaimomentniveaus
3
Gereedschapshouder
1/4'' zeskant uni
Gewicht excl. accu
1 kg
Idle speed, from
0 U/min
Idle speed, up to
3400 U/min
Impact rate, up to
4000 bpm
Onbelast toerental
0-3400 U/min
Onbelast toerental (1e versnelling)
0-800 min-1
Onbelast toerental (2e versnelling)
0-2300 min-1
Onbelast toerental (3e versnelling)
0-3400 min-1
Onbelast toerental, 1e versnelling, tot
800 min-1
Onbelast toerental, 1e versnelling, van
0 min-1
Onbelast toerental, 2e versnelling, tot
2300 min-1
Onbelast toerental, 2e versnelling, van
0 min-1
Packaging dimensions (width x length x height)
185 x 220 x 95 mm
Tool dimensions (length)
113 mm
