Beschrijving
Cordless Orbital Sander GSS 18V-10, The GSS 18V-10 is Bosch's Professional compact and ergonomic cordless orbital sander in the 18 V category. It features an ergonomic palm rest and compact design for easy, comfortable handling. A robust metal sheet provides for durability with extensive use. Its clamping system with hook-and-loop foam pad is designed for the easy changing and replacing of sanding paper. The orbit sander is intended for in-between sanding and finishing of small flat surfaces. It is applicable on wood, veneer, lacquer, filler as well as on mineral and acrylic. Compatible with the Bosch Professional 18V System and with the multi-brand battery alliance AMPShare. The GSS 18V-10 Professional also includes a dust box with a built-in Bosch Micro Filter System, interchangeable pads and is designed to enable one-handed use. Cardboard box, Hole punch (2 608 190 059), Microfilter box, Sanding paper G120, 1 x sanding sheet C470, Best for Wood + Paint, 120 (available separately as set of 10: 2 608 607 458), Base plate, 113 x 101 mm (2 608 601 446) with sanding plate (2 608 601 443)
Specificaties
Accuspanning
18.0 V
Delta schuurplateau met klittenband, breedte
100 mm
Delta schuurplateau met klittenband, lengte
150 mm
Gewicht inclusief accu
1.7 kg
Meetonzekerheid k (plaatmaterial)
1.5 m/s²
Schuurblad met klittenband, breedte
115 mm
Schuurblad met klittenband, lengte
107 mm
Schuurblad voor opspannen, breedte
115 mm
Schuuroppervlak
114 qcm
Schuurpapier voor klemming, lengte
140 mm
Schuurplateau met klittenband en klem, breedte
113 mm
Schuurplateau met klittenband en klem, lengte
101 mm
Schuurplateau met klittenband, breedte
80 mm
Schuurplateau met klittenband, lengte
130 mm
Schuurplateau, breedte
101 mm
Schuurplateau, lengte
113 mm
Trillingsemissie ah [plaatmateriaalslijpen]
7.5 m/s²
Trillingskring diameter
1.6 mm
Trillingsniveau bij onbelast
22000 min-1
Trillingssnelheid bij onbelast, tot
22000 min-1
