Platte dubbele steeksleutel
SW10x11 mm L157 mm Gedore 6 10x11Art.-Nr.: 1028204Leveranciersnummer: 6 10X11EAN: 4010886606476
VPE (Verpakking): 10 stukAantal:
1 stukPakketgeschikt
Artikel in 44 varianten beschikbaar:
Prijs en voorraad zichtbaar na login
Beschrijving
Acc. to DIN 3110, ISO 3318, ISO 1085, ISO 10102, With flat heads, Satin non-glare finish, Jaw: ground precisely to exact nominal size for optimum contact areas, Secure grip thanks to slim profile shaft, Overloading indicated by deformation, Top-grade industrial quality for the hardest of continuous use, Chrome-vanadium steel 31CrV3
Specificaties
Head height 1
4,5 mm
Head width 1
23,5 mm
Head width 2
26,5 mm
Jaw position 1
15 °
Lengte (batterij)
157 mm
Material
31CrV3
Net weight
0,05 kg
Norm
DIN 3110, ISO 3318, ISO 1085, ISO 10102
Sleutelwijdte
10 x 11 mm
Total height
4 mm
Total width
26 mm
Totale lengte
157 mm
Wrench width 1
10 mm
Wrench width 2
11 mm
