Combinatiesleutel DIN 894
SW22 mm L193 mm Gedore 894 22Art.-Nr.: 1028428Leveranciersnummer: 894 22douanetariefnummer: 82041100EAN: 4010886657539
VPE (Verpakking): 10 stukAantal:
1 stukPakketgeschikt
Artikel in 40 varianten beschikbaar:
Prijs en voorraad zichtbaar na login
Beschrijving
Acc. to DIN 894, ISO 3318, Manganese phosphate finish up to 38 mm, steel-grey up from 41 mm, Size 10 - 135 mm with anging hole, Carefully forged and professionally machined: Jaw: ground precisely to exact nominal size for optimum contact areas, Jaw set at 15°, Secure grip thanks to profile shaft - very ergonomic and handy, Overloading indicated by deformation, *not standardised
Specificaties
1000 V isoliert
Nein
Head height 1
8 mm
Head width 1
46 mm
Inhalt
1 Stück
Jaw position
15 °
Material
Vanadium steel 31CrV3
Net weight
0,113 kg
Norm
DIN 894, ISO 3318
Ratschenfunktion
Nein
Sleutelwijdte
22 mm
Surface
manganese phosphatised
Total height
8 mm
Total length
192 mm
Total width
44 mm
VDE zertifiziert
Nein
Wrench width 1
22 mm
